Flow net represents the flow of water through a soil graphically. Discharge passing through the same flow channel is always the same. The shape of the successive flow lines represents gradual transition from one to the other.

Before commencing the calculation, the available published flow nets must be studied and duly analyzed so as to get a rough idea of the nature of the flow net. It is the simplest and the quickest method of flow net construction.

The subsurface flow of water plays an important role for the stability of hydraulic structure like as weir or barrage. The disturbing force at any point is directly proportional to the gradient of pressure of water at that point. THIS GRADIENT PRESSURE OF WATER AT THE EXIT END IS CALLED AS EXIT GRADIENT. Flow nets provide a general knowledge of the regional groundwater flow patterns that the hydrologist can use to determine such information as areas of recharge and discharge. Freeze and Cherry (1979, pg. 168) have stated that flow nets are an important concept of hydrology. The space enclosed by the adjacent equipotential lines and the flow lines must be curvilinear squares. Equipotential lines are formed by connecting the points of equal total head.

In three dimensions, the lines form equipotential surfaces. Hence, in a flow net, where all the figures are square, there is the same quantity of unit flow through each figure and there is the same head drop across each figure. I used finite difference method the concept of which can be easily found in Google search. Applied mirror, impermissive and constant boundary conditions according to dam elements. The FDA formula is easily disrupted by user’s manipulation. If the water table levels are lower than ground level, just consider two water levels in upstream and downstream sides to generate the flow net. The seepage discharge through all the flow channels is the same.

## Design Of Electrical Analogy Apparatus For Drawing Flownet And Studying Uplift Pressure

The line must be at right angles to the upstream and downstream beds. Also, let Δq represent the discharge passing through the flow channel, per unit length of structure . SEEP2D is a two-dimensional finite element groundwater model developed by Fred Tracy of the U.S. SEEP2D is designed to be used on profile models such as cross-sections of earth dams or levees. There is also a pressure in downward direction due to submerged weight of soil.

This method only for a practical method of drawing a flow net for a particular set of boundaries. They by drawing equipotential lines the flow net is completed.

## Why Flow Net Is Important?

It is only applied to problems with simple and ideal boundaries conditions. Streamlines can be traced by injecting a dye in a seepage model or Heleshaw apparatus. Gravel and sand are both porous and permeable, making them good aquifer materials.

The size of the square in a flow channel should change gradually from the upstream to the downstream. Laminar flow is streamlined and directly proportional to the pressure difference. Turbulent flow is a flow without stable streamlines, and it is not directly proportional to the pressure difference. Laminar flow in a cylindrical channel can be seen as a set of steady state parallel streamlines of different velocities. Groundwater modeling is also used to predict contaminant plume movement into the future or to predict the aquifer and plume response to remedial activities.

## Courseintroduction To Ground Water Hydrology Gsci

This gradient of pressure of water at the exit end is called the exit gradient. In order that the soil particles at exit remain stable, the upward pressure at exit should be safe. Other sides of the squares are set equal to the widths as determined above. Irregularities are smoothed out, and the next flow line DF is drawn joining these bases. While sketching the flow line, care should be taken to make flow fields as approximate squares throughout. The flow lines and the equipotential lines must intersect each other at right angles.

Erase and redraw lines until all figures are square. Subdivided as desired for detail and accuracy. Make all lines intersect other set of lines at 90°. It must be ensured that each flow line cut the equipotential lines at right angles to each other. One of the most commonly adopted methods of flow net construction is the graphical method which has been briefly explained below.

This line separates a saturated soil mass from an unsaturated soil mass. It is not an equipotential line, but a flow line. For an earthen dam, the phreatic line approximately assumes the shape of a parabola.

This method requires a lot of erasing to get the proper shape of a flow net and also consume a lots of time. A graphical consists of drawing steamlines and equipotential lines such that they cut orthogonally and form curvilinear squares.

Locate where groundwater is entering and leaving the system. • The stream lines are so spaced that rate of flow Q is same between each successive pair of lines. The most recent for redrawing and improving the entire flow net. Flow nets such errors should be eliminated (i.e., Figs. 4.2d and 4.3e). Graphical method, or Geometric method, allows solving simple linear programming problems intuitively and visually. This method is limited to two or three problems decision variables since it is not possible to graphically illustrate more than 3D.

## What Is Nf Flow Nets?

If the flow fields in the last flow channel are inconsistent with the actual boundary conditions, the whole procedure is repeated after taking a new trial flow line. Computer models may consist of analytical approaches or numerical approaches. Numerical approaches are generally more complex and require specialized knowledge and software. Numerical approaches are also useful for predictive evaluation of proposed remedial solutions and for the evaluation of environmental hazards. One approach to describing fracture flow was developed by Snow . He developed an equation to calculate equivalent hydraulic conductivity for a set of planar fractures. Thus computer modeling has become an important tool in the design of sampling strategies during site monitoring and in the design of groundwater remediation systems.

• • Flow net provides a simple graphical technique for studying tow-dimensional irrotational flows, when the mathematical calculation is difficult and cumbersome.
• As such, a grid obtained by drawing a series of equipotential lines is called a flow net.
• If the curves are drawn properly a circle can be drawn in each field which touches all the four sides of the field.
• This method based on the fact that the flow of fluids and flow of electricity through a conductor are analogus.
• Note that the equation is for laminar flow through porous media.
• Choose equipotential line intervals such that the drop in head between adjacent lines is constant.

An equivalent amount of flow is passing through each streamtube , therefore narrow streamtubes are located where there is more flow. Darcy’s law describes the flow of water through the flow net. Since the head drops are uniform by construction, the gradient is inversely proportional to the size of the blocks. Big blocks mean there is a low gradient, and therefore low discharge . This method based on the fact that the flow of fluids and flow of electricity through a conductor are analogus. These two systems are similar in the respect that electric potential is analogus to the velocity potential. The electric current is analogus to the velocity of flow and the homogeneous conductor is analogus to the homogeneous fluid.

Let b and L be the dimensions of the field and Δh be the head drop through this field. https://personal-accounting.org/ Let us consider an element of soil of size dx, dz through which flow is taking place.

## What Is The Difference Between Flow Net And Flow Field?

Irregular points in the flow field occur when streamlines have kinks in them (the derivative doesn’t exist at a point). In order to draw the flow net, it is first essential to find the location and shape of the phreatic line or the top flow line separating the saturated and unsaturated zones. Draw a trial flow line ABC adjacent to boundary line.

Mathematically, the process of constructing a flow net consists of contouring the two harmonic or analytic functions of potential and stream function. These functions both satisfy the Laplace equation and the contour lines represent lines of constant head and lines tangent to flowpaths . Together, the potential function and the stream function form the complex potential, where the potential is the real part, and the stream function is the imaginary part. Hydrostatic pressure acts below the phreatic line whereas atmospheric pressure exists above the phreatic line. Where HL is the total hydraulic head causing flow, and is equal to the difference of the upstream and the downstream heads.

Measure QH. With F as the centre and QH as the radius, draw an arc to cut vertical line through Q in point P. Now join all the points G, S, P, B to get parabola. The phreatic line must start from B and not from C. Also, the phreatic line is a flow line, and must start perpendicularly to the u/s face AB which is a 100% equipotential line. Phreatic line is a seepage line as the line within a dam section below which there are positive hydrostatic pressures in the dam. The hydrostatic pressure on the phreatic line itself is atmospheric.

They are the lines which join points of equal potential. The flownet can be constructed conveniently for most of the hydraulic structures graphically by trial and error method.

Then, the equipotential lines are drawn such that they cut or intersect the flow lines at right angles. It must be ensured that the equipotential lines are drawn such that the fields form approximate curvilinear squares. 8 Properties of Flow Net The flow lines and equipotential lines meet at right angles to each other. Two equipotential lines never cross each other. Flow and equipotential lines are smooth curves. The quantity of water flowing through each flow channel is the same. A variety of options are provided in GMS for displaying SEEP2D results.

The equation is used in the construction of flow net. Note that the equation is for laminar draw flow nets flow through porous media. Flow through fractured rock may require a different approach.
